Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
PC Health Status
Smart Fan Function (Press Enter)
f
Scroll to this item and press <Enter> to view the following screen:
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
Shutdown Temperature Disabled
Warning Temperature Disabled
CPU Temperature
CPU FAN Speed
SYS FAN Speed
CPU Core
VDIMM
f
: 48°C/118°F
: 2509 RPM
: N/A
: 1.296 V
: 1.872 V
mnlk
: Move
F10: Save ESC: Exit
Enter: Select
+/-/: Value
F9: Load Default Settings
F1: General Help
This item enables you to define the CPU temperature by smartly adjusting the CPU
fan. When it is set at certain temperature, the CPU Fan PWM value will change
accordingly.
CPU SMART FAN Control (Enabled)
SMART Fan start PWM value (28)
This item is used to set the start PWM value of the smart fan.
SMART Fan start PWM TEMP. (°C) (36)
This item is used to set the start temperature of the smart fan.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Smart Fan Function
Help Item
CPU SMART FAN Control Enabled
SMART Fan start PWM value 28
SMART Fan start PWM TEMP. (°C) 36
DeltaT +2
SMART Fan Slope PWM value 3 PWM value/°C
Disabled
Enabled
Options
mnlk
: Move
F10: Save ESC: Exit
Enter: Select
+/-/: Value
F9: Load Default Settings
F1: General Help
