Installing the Motherboard

IR: Infrared header (optional)

The motherboard supports an Infrared (IR) data port. Infrared ports allow the wire-

less exchange of information between your computer and similarly equipped devices

such as printers, laptops, Personal Digital Assistants (PDAs), and other computers.

1 Not Assigned Not assigned

2 Key No pin

3 +5V IR Power

4 GND Ground

5 IR_TX IrDA serial output

6 IR_RX IrDA serial input

Pin Signal Name Function

Questions and Answers:

Need help?

Do you have a question about the ECS MCP61M-M3 and is the answer not in the manual?

ECS MCP61M-M3 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS memory size	64 Mbit
