ECS MCP61M-M3 User Manual

34
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Serial-ATA 0 Enabled
SATA Configuration SATA Mode
nVidia RAID Setup Press Enter
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
OnBoard IR Disabled
USB Functions Enabled
Legacy USB Support Enabled
f
DISABLED: disables the
integrated IDE Control-
ler.
PRIMARY: enables only
the Primary IDE Control-
ler.
SECONDARY: enables
only the Secondary IDE
Controller.
BOTH: enables both IDE
Controllers.
SATA Configuration (SATA Mode)
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Serial-ATA 0 (Enabled)
This item allows you to enable or disable the onboard SATA controller.
Use this item to show the mode of the Serial ATA configuration options.

ECS MCP61M-M3 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS memory size	64 Mbit
