2
Introducing the Motherboard
Feature
Processor
HyperTransport
TM
Technology is a point-to-point link between two devices, it
enables integrated circuits to exchange information at much higher speeds than
currently available interconnect technologies.
• Accommodates AMD Phenom
TM
II (socket AM3) processor
• Supports up to 2000 MT/s HyperTransport
TM
(HT) interface Speeds
• High-performance HyperTransport CPU Interface
This motherboard uses a socket AM3 that carries the following features:
• DDR3 1333/1066/800 DDR3 SDRAM with Dual Channel supported
•
Accommodates two unbuffered DIMMs
•
2 x 240-pin DDR3 DIMM sockets support up to 8 GB
Memory
Audio
• 5.1 Channel High Definition Audio Codec
• Exceeds Microsoft Windows Logo Program (WLP) Requirements
• ADCs support 44.1/48k/96k/192k sample rate
• Power Support: Digital: 3.3V; Analog: 5.0V
The onboard Audio provides the following features:
The NVIDIA
®
MCP61P is a single-chip with proven reliability and performance.
• 1 GHz HyperTransport x16 up and down links to the AMD socket
AM2+/AM2 CPUs
• PCI Express 16 lane link interface for external graphics processors
•
PCI v2.3 interface at 33 MHz
•
Integrated SATA 3.0 Gb/s Host Controller
• Ten USB 2.0 ports supported
• Fast ATA-133 IDE controller
Chipset
This board supports CPU up to 95W TDP only.
Onboard LAN (optional)
The onboard LAN provides the following features:
• 10/100 full/half duplex operation
• Support MIl and 7-wire SNI (Serial Network Interface)
• IEEE 802.3/802.3u compliant
• 1000Base-T IEEE 802.3ab Compliant
• 100Base-TX IEEE 802.3u Compliant
• 10Base-T IEEE 802.3 Compliant
• IEEE 802.3 Compliant RGMII
• Supports Auto-Negotiation
• Supports half/full duplex operation
• 0.11um process with very low power consumption
