Introducing the Motherboard

Table of Motherboard Components

This concludes Chapter 1. The next chapter explains how to install the motherboard.

LABEL CO MPONENTS

1. CPU Socket Socket for AMD Phenom

II (socket AM3) processor

2. CPU_FAN CPU cooling fan connector

3. DDR3_1~2 240-pin DDR3 SDRAM slots

4. CASE Chassis detect header

5. FDD Floppy disk drive connector

6. PWR Standard 24-Pin ATX power connector

7. IDE Primary IDE connector

8. SATA1~4 Serial ATA connectors

9. PANEL Front panel Switch/LED header

10. F_USB1~3 Front panel USB headers

11. USBPWR_F Front panel USB power select jumper

12. SPK Speaker header

13. CLR_CMOS Clear CMOS jumper

14. SYS_FAN System cooling fan connector

15. CD_IN Analog audio input header

16. F_AUDIO Front panel audio header

17. SPDIFO SPDIF out header

18. PCI1~2 32-bit add-on card slots

19. PCIEX1 PCI Express x1 slot

20. PCIEX16 PCI Express x16 graphics card slot

21. ATX12V 4-pin +12V power connector

22. USBPWR_R Rear USB/PS2 power select jumper

Questions and Answers:

Need help?

Do you have a question about the ECS MCP61M-M3 and is the answer not in the manual?

ECS MCP61M-M3 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS memory size	64 Mbit
