Page #144 background imageLoading...
Page #144 background image
Vital Signs Monitor User Manual Product Specification
- 136 -
Adult Mode
SYS: 40 mmHg to 270 mmHg
DIA: 10 mmHg to 215 mmHg
MAP: 20 mmHg to 235 mmHg
Pediatric Mode
SYS: 40 mmHg to 230 mmHg
DIA: 10 mmHg to 180 mmHg
MAP: 20 mmHg to 195 mmHg
Neonatal Mode
SYS: 40 mmHg to 135 mmHg
DIA: 10 mmHg to 100 mmHg
MAP: 20 mmHg to 110 mmHg
Alarm Type
SYS, DIA, MAP
Cuff Pressure Measuring
Range
0 mmHg to 300 mmHg
Pressure Resolution 1 mmHg
Maximum Mean Error
±5 mmHg
Maximum Standard Deviation
8 mmHg
Maximum Measuring Period
Adult/Pediatric 120 s
Neonate 90 s
Typical Measuring Period 20 s to 35 s (depend on HR/motion disturbance)
Dual Independent Channel Overpressure Protection
Adult (297±3) mmHg
Pediatric (245±3) mmHg
Neonatal (147±3) mmHg
Pre-inflation Pressure
Adult Mode Default: 160 mmHg
Range: 80/100/120/140/150/160/180/200/220/240 mmHg
Pediatric Mode Default: 140 mmHg
Range: 80/100/120/140/150/160/180/200 mmHg
Neonatal Mode Default: 100 mmHg
Range: 60/70/80/100/120 mmHg
