EDAN iM3 User Manual

Vital Signs Monitor User Manual Product Specification
- 144 -
A.10 Interfaces
A.10.1 Nurse Call
Drive Mode Voltage output
Power Supply 3.14 V ~ 3.46 V, 8 mA MAX
Interface Signal 3.3 V power supply and PWM waveform
Interface Type Micro USB
A.10.2 USB Interfaces
A.10.3 OTG Interfaces
A.10.4 Wired Network Interface
Specification 100-Base TX (IEEE802.3)
Interface Type Standard RJ-45 network interface
Number of USB Interfaces Standard:1
Drive Mode HOST interface, USB1.0/2.0 protocol
Power Supply 5 VDC±5%, 500 mA Max.
Interface Type USB A-type port
Number of USB Interfaces Standard: 1
Drive Mode USB OTG interface, USB1.0/2.0 protocol
Power Supply Output: 5 VDC±5%, 500 mA Max.
Input: 5 VDC±5%, 100 mA Max.
Interface Type Micro USB port
