Page #23 background image
Vital Signs Monitor User Manual Basic Operation
- 15 -
1 Portable handle/Accessory collecting: for lifting or moving the
monitor or collecting the accessories
2 Battery compartment latch: for opening or closing battery door.
3 Equipotential grounding terminal. If the monitor is used together
with other devices, connect this terminal to eliminate potential
ground differences between devices.
4 AC power input: for connecting AC power cable
5 Power cable safety latch. Used to prevent the power cable from
loosing or falling. Place the latch on the power cable and fasten
it firmly from right to left to ensure that it secures the power
cable.
6 OTG interface/nurse call port.
OTG interface: it connects the monitor to computer via
data-line. The data in monitor can be transmitted to
computer.
Nurse call port: it connects the monitor to the hospital’s
nurse call system. Alarms indications are alerted through the
nurse call system if configured to do so.
NOTE:
During connecting USB flash drive via OTG interface, if the
USB flash drive cannot be recognized, please try to re-plug
USB flash drive.
7 USB interface: for connecting the approved USB device.
8 Network interface. It connects the monitor to the central
monitoring system (also named as MFM-CMS, and MFM-CMS
V2.64 or above is recommended) or to Gateway (V1.21 or
above) via standard network cable.
9 Battery door: for fixing or replacing the battery.
