Patient Monitor User Manual Monitoring ECG/ RESP
- 111 -
The system displays the QRS complex template in the window. It is adjustable for the highlight
bar in the window. You may select ISO or ST, switch the knob left or right to move the cursor
line. When the cursor is at the required position, you may select the base point or the
measurement point.
NOTE:
Abnormal QRS complex is not considered in ST segment analysis.
ST Alarm Message
NOTE:
The alarm limits for two ST measurements are identical. No setting of alarm limits can be
made only for one channel.
If the ST values are too high or too low, the monitor will give alarms for these parameters of ST
value.
ST-Ⅰ, ST-Ⅱ, ST-Ⅲ, ST-AVR, ST-AVL, ST-AVF, ST-V
13.7 Arr. Monitoring (Optional)
Arrhythmia Analysis
The arrhythmia algorithm is used to monitor ECG of adult patients in clinical, detect the change
of heart rate and ventricular rhythm, and also save arrhythmia events and generate alarming
information. The arrhythmia analysis is not clinically validated for use with neonatal and
pediatric patients. Arrhythmia algorithm can monitor paced and non-paced patients. Qualified
personnel can use arrhythmia analysis to evaluate patient’s condition (such as heart rate, PVCs
frequency, rhythm and ectopic beat) and decide the treatment. Besides detecting change of ECG,
arrhythmia algorithm can also monitor patients and give proper alarm for arrhythmia.
The arrhythmia monitoring is shut off by default. You can enable it when necessary.
This function can call up the doctor's attention to the patient's heart rate by measuring and
classifying the arrhythmia and abnormal heart beat and triggering the alarm.
The monitor can conduct up to 16 different arrhythmia analyses.
Pick the item ARR ANALYSE in ECG SETUP menu to access the ARR ANALYSE
sub-menu.
The monitor has a Pacing impulse detection circuit (select one from I, II, III, AVR, AVL,
AVF and V).
Every ECG channel has a Pacing impulse rejection and a Band pass filter circuit. Pacing rate >
320 mV/s (RTT).
