Measuring Range
0 C to 50 C (32 ºF to 122 ºF)
Resolution
0.1 C (0.1 ºF)
☆Accuracy
1
0.3 C
Refresh Time
Every 1 s to 2 s
Transient Response Time
≤30 s
Temperature Calibration
At an interval of 5 to 10 minutes
Note 1: The accuracy consists of two parts, as following:
(1) Accuracy (not including sensor): ±0.1 C
(2) Sensor accuracy: ≤±0.2 C
A1.2.14 IBP (Optional)
Complies with IEC 60601-2-34: 2011.
Technique
Direct invasive measurement
☆Measuring range
Art
0 mmHg to +300 mmHg
PA
-6 mmHg to +120mmHg
CVP/RAP/LAP/ICP
-10 mmHg to +40 mmHg
P1/P2
-50 mmHg to +300 mmHg
Resolution
1 mmHg
☆Accuracy (not including
sensor)
2% or 1 mmHg, whichever is greater
Unit
kPa, mmHg, cmH2O
Zero calibration range
200 mmHg
Filter
DC～12.5 Hz; DC～40 Hz
Pressure sensor
Sensitivity
5 (μV/V/mmHg)
Impedance
300 Ω to 3000 Ω
Volume Displacement
7.4 x 10
4
mm
3
/100mmHg
A1.2.15 CO
2
(Optional)
Complies with ISO 80601-2-55: 2011.
EDAN EtCO
2
Module
Intended
patient
Adult, pediatric, neonatal
