EDAN iM8 - A1.2.10 Nibp

Patient Monitor User Manual Specifications
- 173 -
Neo/Ped
6 rpm to 150 rpm: 2 rpm
0 rpm to 5 rpm: Undefined
Respiration excitation
waveform
<500 μA, sinusoid, 62.8 kHz (10%)
Measuring Sensitivity
Within baseline impedance range: 0.3 Ω
☆Gain selection
0.25, 0.5, 1, 2, 3, 4, 5
☆Sweep
6.25 mm/s, 12.5 mm/s, 25.0 mm/s, 50.0 mm/s
Measurement lead
Options are lead I and II. The default is lead II.
Calculation Type
Manual /Automatic
Measuring sensitivity
0.3 Ω (baseline impedance 200 Ωto 4500 Ω)
Maximum dynamic range
Baseline impedance: 500 Ω
Variable impedance: 3 Ω
No clipping
Baseline Impedance Range
200 Ω to 2500 Ω(with ECG cables of 1 KΩ resistance)
Waveform bandwidth
0.2 Hz to 2.5 Hz (-3 dB)
☆Apnea Alarm Time
10 s, 15 s, 20 s, 25 s, 30 s, 35 s, 40 s; default value is 20 s.
A1.2.10 NIBP
Complies with IEC 80601-2-30: 2009+A1: 2013
Method
Oscillometric
Mode
Manual, Auto, Continuous
Measuring Interval in AUTO
Mode (unit: min)
1/2/3/4/5/10/15/30/60/90/120/240/480
Continuous
5 min, interval is 5 s
Measuring Type
SYS, DIA, MAP, PR
☆Alarm Type
SYS, DIA, MAP
☆Measuring Range
