Patient Monitor User Manual Recording (Optional)
- 75 -
Trend table recording
Access the TREND TABLE menu, then press the
RECORD button to start recording.
Arrhythmia review recording
Enter the ECG SETUP menu via hot key, select ARR
ANALYSE > ARR RECALL, then press the RECORD
button to start recording.
Alarm review recording
Access the ALARM RECALL menu, then press the
RECORD button to start recording.
NIBP review recording
Access the NIBP RECALL menu, then press the
RECORD button to start recording.
Titration table recording
Access the DRUG CALC menu from the SYSTEM
MENU. Pick the TITRATION button in the menu to
access the TITRATION window. Pick the REC button to
print out the titration currently displayed in the window.
Frozen waveform recording
8-second frozen waveform can be recorded, 2 waveforms
are selectable.
NOTE:
You can press the RECORD button on the control panel to stop the current recording
process.
Access the RECORD menu from the SYSTEM SETUP menu. Then pick the CLEAR REC
TASK button to stop all recording tasks.
9.4 Recorder Operations and Status Messages
Record Paper Requirement
Only standard thermosensitive record paper can be used: otherwise the recorder may not function,
the recording quality may be poor, and the thermosensitive printhead may be damaged.
Proper Operation
 When the recorder is working, the record paper goes out steadily. Do not pull the paper
outward with force: otherwise the recorder may be damaged.
 Do not operate the recorder without record paper.
Paper Out
When RECORDER OUT OF PAPER alarm is displayed, the recorder cannot start. Please
insert record paper properly.
Inserting Paper
 Pull outwards the upper arc part of the recorder casing to release the casing.
