C
HAPTER
2
| Network Planning
Application Examples
– 34 –
REMOTE CONNECTIONS WITH FIBER CABLE
Fiber optic technology allows for longer cabling than any other media type. A
1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a
1000BASE-LX (SMF) link up to 10 km, and a 1000BASE-LH link up to 80 km.
This allows the switch to serve as a collapsed backbone, providing direct
connectivity for a widespread LAN.
The figure below illustrates the switch connecting multiple segments with fiber
cable.
Figure 7: Remote Connections with Fiber Cable
