C HAPTER 3 | Installing the Switch
Mounting
– 41 –
Figure 10: Attaching the Brackets
2. Mount the device in the rack, using four rack-mounting screws (not
provided). Be sure to secure the lower rack-mounting screws first to
prevent the brackets being bent by the weight of the switch.
Figure 11: Installing the Switch in a Rack
