C HAPTER 4 | Making Network Connections
Fiber Optic SFP Devices
– 49 –
Figure 17: Making Fiber Port Connections
4. As a connection is made, check the Link LED on the switch corresponding to
the port to be sure that the connection is valid.
The 1000BASE-SX, 1000BASE-LX, 1000BASE-LH fiber optic ports operate at
1 Gbps, full duplex, with auto-negotiation of flow control. The maximum length
for fiber optic cable operating at Gigabit speed will depend on the fiber type as
listed under “1000 Mbps Gigabit Ethernet Collision Domain” on page 50.

Edge-Core ECS4310-18T Specifications

General

Number of Ports	18
Switching Capacity	36 Gbps
Forwarding Rate	26.78 Mpps
Power Consumption	20.3W
Dimensions	440 x 250 x 44 mm (17.32 x 9.84 x 1.73 in)
Weight	2.7 kg (5.95 lbs)
Ports	16 x 10/100/1000BASE-T 2 x 1G/10G SFP+
MAC Address Table Size	8K
Power Supply	Internal Power Supply
Product Type	Switch
Port Type	10/100/1000 Mbps
Layer	Layer 2
Jumbo Frame Support	9K bytes
