Edge-Core ES4524D User Manual

3-7
Connecting to the Console Port
3
Wiring Map for Serial Cable
The serial port’s configuration requirements are as follows:
• Default Baud rate—9,600 bps
• Character Size—8 Characters
• Parity—None
• Stop bit—One
• Data bits—8
• Flow control—none
Table 3-1 Serial Cable Wiring
Switch’s 8-Pin
Serial Port
Null Modem PC’s 9-Pin
DTE Port
6 RXD (receive data) <---------------------------- 3 TXD (transmit data)
3 TXD (transmit data) -----------------------------> 2 RXD (receive data)
5 SGND (signal ground) ------------------------------ 5 SGND (signal ground)
No other pins are used.
