Dishwasher Components
Outer Door
The outer door panel covers the inner door to the dishwasher and must he removed to
access the detergent/rinse module and bottom door seal.
To remove the outer door panel, first remove the 6 screws, and then separate the panel
from the inner door.
Control Panel
The control panel consists of the PCB user interface board. To remove the control
panel:
1. Disconnect the power supply to the dishwasher.
2. Remove the 8 screws.
