Edgewater Networks 268CC - Switch Template

12
Lenco Marine
Switch Wiring #15069-001 (124SSR)
Switch
Template
Page 27
Note: In all cases,
make sure control box
is mounted with wires
facing down
toward deck.
# 15069-001 (124SSR)
This product must be wired exactly as shown above.
Failure to wire the trim tab retractor as shown will cause
cancellation of all warranties by the manufacturer.
