Chapter2:AbouttheProduct

2.1LEDDefinitions



LED Status Description

LAN
Green LANportconnected
Blinking LANactivity(transferringdata)
Of
f
 LANportnotconnected

PLC
Green/Yellow
Thegreenindicatorturnsonandtheyellowindicator
blinksslowlywhenthedeviceisdetectinga
powerlinelink.
Thegreenindicatorturnsonandtheyellowindicator
blinksquicklytoindicatedataisbeingtransferred
overthepowerlinelink.
Of
f
 Noother PLC device detected

PWR
Green Poweredon
Of
f
 Poweredof
f

Note:Thedevicewillenterstandbymode,andallLEDswillextinguish,after
5secondswithoutanydatatransfer,includingwhentheEthernetcableis
disconnected.ThePowerLEDwillflashonceevery15seconds.



