1.4 Familiar with Key Components
Item
Description
Power
When the camera is powered on and ready for access, this LED
will light up.
Audio
Indicates Audio status
LAN
When the IP Camera is linked to a wired network, this LED will
light up. The LED will flash while video is transmitted or
received through a wired network.
ACT
(IC-7010
The LED will flash while data is transmitted.
Front View
Focus Ring
IR LED
Microphone
Wired & Wireless:
POE model:
Power LED Audio LED LAN LED WLAN LED
Power LED Audio LED ACT LED LAN LED
