Edimax IC-7110 - Page 13

12
IC-7110P:
Item
Description
Power
Connector
Connects to 12V DC power adapter
SD Card Slot
Accepts SD / SD-HC memory card for image / video
storage
USB Port*
(IC-7110
only)
Accepts USB WiFi adapter** to enable wireless
Audio
Connector
Connects to external speaker for audio output
Ethernet
Connector
Connect to your local area network
Power
Connector
SD Card Slot
Audio Connector
Ethernet Port
