Edimax IC-7110 - Key Components

8
1.4 Key Components
Item
Description
Power/Cloud
The power LED will flash and light up when the camera is
powered on and ready for access to Cloud.
Audio
Indicates Audio status
LAN
When the Network Camera is linked to a wired network, this
LED will light up. The LED will flash while video is transmitted
or received through a wired network.
ACT
(IC-7110P only)
The LED will flash while data is transmitted.
Front View
Focus Ring
IR LED
Microphone
Wired & Wireless:
POE model:
Power LED Audio LED LAN LED WLAN LED
Power LED Audio LED ACT LED LAN LED
