Transition Effects List

Mix Effects

The effect gradually blends the picture into another.

Wipe Effects

The effects like windshield wiper on a car. The present picture is wiped off as it changes to

another...

Hard Edge type

V-4_e.book 98 ページ２０１０年３月１１日　木曜日　午後１時５１分
