EDWARDS SYSTEMS TECHNOLOGY CMDN - LED Operation

8 CMDN Manual
Sample IRC-3/FCC Alarm Message:
JAN 23 01:12:56 M123
FIRE ALARM LLPPZZ
Custom Label entered
thru the IBM compatible PC
= Date, time, # of unacknowledged messages (123)
= Alarm type and alarm zone address
= Custom message on two lines (20 x 2)
Sample messages are shown below for annunciators connected to
LSS4 fire alarm panels:
No Messages Pending:
SCREEN LABEL M000
= Screen label and # unacknowledged messages (LSS4 only)
Sample Alarm Message:
SCREEN LABEL M023
FIRE ALARM 000052
Custom Label entered
thru the IBM PC
= Screen Label and # unacknowledged messages
= Alarm Type and Alarm zone address
= Custom message on two lines
LED Operation
LED Indicators
Indicator USA Canada Europe
Normal LED Steady Steady Steady
Alarm LED Steady Flashing until acknowledged Steady
Trouble LED Steady Flashing until acknowledged Steady
Supervisory LED Steady Flashing until acknowledged Steady
