12 CMDN Manual
Installation
Specifications
Specifications
Power 18.4 - 24 VDC @ 80 mA
Inter-annunciator Communications
(FCC mode only)
Style 4 or 7 (Class B or A), RS-485
Host Quantity/Addressing:
LSS4
IRC-3
FCC/DCPU
4 annunciators at address 15, using 4 sub-addresses.
Up to 4 network addresses per annunciator.
32 per DCPU display port.
Maximum Wire Length:
RS-232
RS-485
50' (15 M)
FCC mode: 7,700’ (2348 M) #18 AWG Twisted Pair
LSS4 Mode: 4,500’ (1372 M) #18 AWG Twisted Pair
(Refer to the Network Hardware Technical Reference,
P/N 250100-1, for additional wiring specifications.)
Maximum Wire Size Two # 18 AWG per Terminal
Inter-annunciator Communications
Baud Rate
2400, 4800, 9600, 19200
Printer Port Format RS-232
Printer Baud Rate 2400, 4800, 9600
Message Capacity:
LSS4
IRC-3
FCC
52 Messages per annunciator
88 Messages per panel address, 352 Max. per annunciator.
650 Messages per annunciator.
Dimensions (H, W, D):
CMDN (-S) Faceplate
CMDN (-S) Enclosure
SMDN (-S)
SAN-4 Finished
SAN-4 Rough-In
SAN-8 Finished
SAN-8 Rough-In
RSAN-6
8" x 7" (20.3 cm x 17.8 cm)
7 1/4" x 6 1/8" x 3 3/4" (18.4 cm x 15.6 cm x 9.5 cm)
2 SAN Module Spaces
11.5" x 16.0" x 4.0" (29.2 cm x 40.6 cm x 10.2 cm)
9.5" x 11.25" x 2.5" (24.1 cm x 28.6 cm x 6.4 cm)
11.5" x 27.5" x 4.0" (29.2 cm x 69.9 cm x 10.2 cm)
9.5" x 23.0" x 2.5" (24.1 cm x 58.4 cm x 6.4 cm)
10.5" x 19.0" x 2.5" (26.7 cm x 48.3 cm x 6.4 cm)
SMDN and SMDN-C Installation
The SMDN-C mounts in the SAN-4 or SAN-8 annunciator cabinets or
in the RSAN-6 rack mount frame for use with CB 17, 31, and 45
enclosures. The SMDN or SMDN-C alphanumeric display annunciator
requires two SAN module spaces. Install the annunciator in the SAN
enclosure/frame with the hardware provided.
