26 CMDN Manual
Remote Alpha-Numeric Display Network
PROJECT SELECTION
Project Name : _________
Project Description:_________________
Enter number of product:
1 for FCC Class A
2 for FCC Class B
3 for IRC-3
4 for LSS
Enter Number : _________
Project Name: (8 char max) is used to identify a specific project.
Alphanumeric characters - no spaces.
Project Description: (20 char max) provides a description of the project.
Type: defines the fire panel model associated with this project.
For annunciators operating in the IRC-3 and FCC modes, continue with
the next section. For annunciators operating in the LSS4 mode,
continue with the LSS4 Configuration section.
IRC-3(FCC/PCPU) and FCC/DCPU RS-485
Data Line Configuration
IRC-3(FCC/PCPU) and FCC/DCPU Phase 1 - Parameter
Entry for Entire Project
The “Parameter Entry for Entire Project” screen is divided into three
sections: the Network Status Window (top), the Menu Window
(middle), and the Instructions Window (bottom), as shown in the IRC-
3 and FCC menus below.
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
PARAMETER ENTRY for ENTIRE PROJECT
PROJECT NAME: Select Base Address: 5
Project Description:
Q(nBR) of Addresses: 1 PC Communications Port: 1
Geographic Category: USA
Type: IRC3 Communications Baud Rate: 9600
S Select base address to start a block of 1-4 addresses
Q Select Number of Addresses P Select PC Communications Port
G Select Geographic Category B Select Communications Baud Rate
V Show Version
INSTRUCTIONS
Press any highlighted letter to alter the corresponding item.
Press TAB to move to the next screen and enter data to the
Selected Display shown above. The data here will be saved.
Press ESC to exit this program.
IRC-3 Project Menu
