CMDN Manual 25
Starting the Configuration Program
Start the CMDN configuration program by typing:
CD\CMDN
CMDN
The opening screen, shown below, requests a 1 to 8 character project
name, which is used as the filename for all files relating to this project.
If a project name has been previously entered, typing in the project
name will open its files, and the next two steps will be skipped.
Remote Alpha-Numeric Display Network
PROJECT SELECTION
Enter Project Name : _________
Project Name: (8 char max) is used to identify a specific project.
Alphanumeric characters - no spaces.
Project Description: (20 char max) provides a description of the project.
Type: defines the fire panel model associated with this project.
The first time a filename has been entered, a project description may be
entered. This information appears on all project configuration reports.
Press the ENTER key to bypass this step. The project description
screen follows:
Remote Alpha-Numeric Display Network
PROJECT SELECTION
Enter Project Name : _________
Enter Project Description:_________________
Project Name: (8 char max) is used to identify a specific project.
Alphanumeric characters - no spaces.
Project Description: (20 char max) provides a description of the project.
Type: defines the fire panel model associated with this project.
The type of host system to which the CMDN will be connected is
entered using the respective index number, as shown on the Next
screen. Enter a “1” or “2” for Class A or Class B FCC systems,
respectively. Enter a “3” when configuring the annunciator for IRC-3
(or FCC/PCPU) data line operation, and a “4” when configuring the
annunciator for use with an LSS4 panel.
