CMDN Manual 33
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
MESSAGE ENTRY/EDITING for SELECTED DISPLAY
Current Project File: Selected Display: FCC
Project Name: Printer:
Location: Baud Rate:
Annunciation Type(s): Routing:
Active When Enabled: Current Msg:
Active When Disabled: Total Msgs:
_____________ _____________
Line: Panel: Zone: [_____________] [_____________]
INSTRUCTIONS
Press UP or DN ARROW Keys until the desired line value appears above.
Choices 0, 2, 4, or 6
Press RT ARROW to enter panel
Press ENTER key to accept value shown, then do panel.
Press ESC to exit from message entry.
FCC Message Entry/Edit Screen
Configuring the Balance of Annunciators on an FCC Network
When the first annunciator (address 01) has been completely
configured, return to the opening screen and increment the Selected
Display parameter to the next annunciator address and repeat
programming Phase 2 for the next annunciator. When all annunciators
have been configured, proceed to the Downloading to the
CMDN/SMDN section for instructions on downloading.
Note: The DCPU port should be configured in the DCPU Database as a
“Display” port using the FCC Compiler program.
LSS4 Configuration
Phase 1 - Parameter Entry for Entire Project
The “Parameter Entry for Entire Project” screen is divided into three
sections: the Status Window (top), the Menu Window (middle), and the
Instructions Window (bottom), as shown in the LSS4 menu below.
Current time and date information is displayed above the status
window. The Status Window shows the current settings of the
annunciator parameters.
