18 CMDN Manual
CH A CH B
TTRT/R T/RRCC
CMDN(C)/SMDN(C)
FCOM-232
(INSTALLED IN DCPU)
CMDN(C)/SMDN(C) CMDN(C)/SMDN(C)
11122233344455566677788899910 10 10
(REAR VIEW) (REAR VIEW) (REAR VIEW)
TB1 TB1 TB1
+++
24 VDC
IN
24 VDC
IN
24 VDC
IN
PROVIDE PHYSICAL SEPARATION BETWEEN
THESE WIRE BUNDLES TO INSURE NETWORK SURVIVABILTY
[CMDN-014.CDR]
PIN 1 PIN 14
PIN 13 PIN 25
DB25 MALE
(REAR VIEW)
23 7
50 FT. (15.2 M.) MAX.
NON-SUPERVISED
TO PT1-S SERIAL PRINTER
111
1
24VDC SUPPLY MUST HAVE DEDICATED RISER
NOTE
Class A FCC/DCPU Display Port Wiring
