CMDN Manual 35
PC Communications Port: Press the UP and Down arrow keys, or key
the number directly, until the desired PC serial port number for
download/upload appears in the window.
Detailed parameter specifications may be found in the Parameter
Descriptions and Specifications section. A full list of keyboard
commands appear in the Keyboard Commands section.
When all required parameters have been entered in the “Parameters for
Entire Project” menu, press the TAB key to save the previous entries
and step to the “Parameter Entry for Selected Display” menu.
Phase 2 -Parameter Entry for Selected Display
After the network environment parameters have been entered, each
CMDN/SMDN must be configured (phase 2). The “Parameter Entry
for Selected Display” screen is the first of two screens used to
configure each CMDN/SMDN (phase 2), and enter its messages (phase
3).
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
PARAMETER ENTRY for SELECTED DISPLAY
Current Project File: Selected Display: 1 LSS
Project Name: Printer: NONE
Screen Label: Baud Rate: 9600
Annunciation Type(s): Alarm + Supervisory + Trouble Routing: All Messages
Active When Enabled:
Active When Disabled:
L Enter Screen Label P Select Printer
A Select Annunciation Type(s) B Select Comm Baud Rate
E Select Active When Keyswitch Enabled R Select Routing of Mess
D Select Active when Keyswitch Disabled T Transmit to Display
N Set to No Switch Panel H Print Hard Copy (or File)
INSTRUCTIONS
Press letters R, A, L, E, D, or B to alter the corresponding item.
Press letters N, T, or H to execute the action stated.
Press TAB to move to the next screen and enter or edit messages.
The Selections shown Above will be saved.
Press ESC to return to prior menu-Selections shown will be saved.
LSS4 Selected Display Menu
1 Verify that the address of the desired annunciator appears in "Select
Display" window. Normally the annunciators are configured in
order, starting with #1. If the desired screen is not displayed, press
ESC to return to the prior window, then press S, and enter the
correct display number. Press return then TAB to return to the
second screen.
Note: All information displayed on this screen applies to the CMDN/
SMDN whose address is displayed in the Selected Display box.
2 Enter the required annunciator information for the parameters listed
below. Key in 12 characters for the screen label. Press ENTER to
accept the screen label or ESC key to abort and retain the prior
location. Press A to select annunciation type(s). Use the arrow keys
to select from the available options shown in the window.
Screen Label
Annunciation Type(s)
Active when Key switch Enabled
