EDWARDS SYSTEMS TECHNOLOGY EST2 - Page 74

P/N: 270650 REV: 2.0 Page 2 of 2
Cover
27.41 in (69.6 cm)
27.12 in (68.9 cm)
2.5 in (6.4 cm)
11.5 in
(29.2 cm)
9.5 in
(24.1 cm)
Front view
Top view
Side view
1.4 in (3.6 cm)
DIMENSIONS
Front view
10.5 in (26.7 cm)
19 in (48.3 cm)
Knockout for 0.75 in (1.9 cm)
conduit (both sides)
22.37 in (56.8 cm)
Six module mounting frame
Eight module enclosure
