Installation
D374-20-880 Issue E
3 Installation
3.1 Unpack and Inspect
Remove all of the packaging materials and check the iTIM. If the iTIM is damaged, notify your supplier and the carrier
in writing within three days, stating the item number of the iTIM together with your order number and your suppliers
invoice number. Do not use the iTIM if it is damaged.
Check that you have received the items listed in Table 1. If any item is missing, notify your supplier in writing within
three days. If you will not use the iTIM immediately, replace any packing materials and store it in suitable conditions,
as described in Section 7 of this instruction manual.
3.2 Fit the iTIM
Before the iTIM is fitted, the electrical supply to the dry pumping system must be isolated.
CAUTIO N
The iTIM may be damaged if it is disconnected while the pump is powered.
The iTIM can be directly fitted to a dry pumping system.
To fit the iTIM directly to a dry pumping system:
1. Remove active gauge bung.
2. Refer to Figure 4. Fit the pumping system mounting tabs into the fixing slots on the rear panel of the dry
pumping system.
3. Position the (captive) pumping system mounting screws into the fixing holes on the rear panel of the dry
pumping system, then tighten the screw to secure the iTIM in place.
3.3 Connect the iTIM to the Dry Pumping System
Use the following procedure to connect the iTIM to the dry pumping system, and (optionally) to another pumping
system module; where necessary, refer to the instruction manual supplied with the dry pumping system.
1. On an iH or iL dry pumping system, remove the 6-way XLR terminator plug or the module connector cable from
the OEM connector on the Electrics and Pump control box.
2. Insert the 6-way XLR connector on the short lead that comes out of the iTIM into the OEM connector on the
Electrics and Pump Control Box.
Table 1 - Checklist of items
Quantity Description Check (✔)
1iTIM
❏
2 iTIM Instruction Manual ❏
