Introduction
D374-20-880 Issue E
1Introduction
1.1 Scope and definitions
This manual provides installation, operation and maintenance instructions for the Edwards iTIM. You must use the
iTIM as specified in this manual.
Read this manual before you install, operate and maintain the iTIM. Important safety information is highlighted as
WARNING and CAUTION instructions; you must obey these instructions. The use of WARNINGS and CAUTIONS is defined
below.
CAUTIO N
Cautions are given where failure to observe the instruction could result in damage to the equipment, associated
equipment and process
Throughout this manual, page, figure and table numbers are sequential.
The units used throughout this manual conform to the SI international system of units of measurement; US equivalent
units of measurement are also given.
The following IEC warning labels appear on the iTIM:
1.2 General Description
Four types of iTIM are available (refer to Figures 1 and 2):
z There are two variants of the iTIM both of which allow you to control the operation and monitor the status of
the dry pumping system through a parallel interface (for example, connected to your process tool).
z The serial option of the iTIM contains a serial interface card, which allows the user to control the operation
and to monitor the status of the dry pumping system through a serial interface. The serial interface card uses
RS232 serial communications to communicate with your control equipment (refer to Section 5).For example,
it is possible to connect the iTIM to the serial port of a PC (Personal Computer) on which a suitable SCADA
(Supervisory Control And Data Acquisition program) has been installed.
Note: All information sent to or received from the iTIM, except from the emergency stop connections, (Whether
serial or parallel data) is software derived.
WARNING
Warnings are given where failure to observe the instruction could result in injury or death to
people.
Warning - refer to accompanying documentation.
WARNING
Edwards take no responsibility for damage or injury caused by improper use of the equipment.
