Introduction
1.3 System Connector
Refer to Figure 1. The iTIM is connected to the dry pumping system through the 15-way ‘D-Type’ system connector
(10) on the rear of the iTIM.
CAUTIO N
Damage to the iTIM may result if connection is made to any other connector on the dry pumping system.
1.4 The Tool Interface Connectors
The Tool Interface Connectors allow you to control the operation and to monitor the status of the dry pumping
system.
Refer to Section 2.3 for details of the connections and 4 for details of how to use the Tool Interface Connectors.
1.5 Serial Interface Connectors
The Serial Interface Connectors allow you to control the operation and to monitor the status of the dry pumping
system.
Refer to Section 3.5 for details of the connections and 5 for details of how to use the Serial Interface Connectors.
