D374-20-880 Issue E
Page 28 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Serial Interface Operation
14 Total running time 0 0 0 207
16 Hours on process 0 0 0 3
18 Process cycles 0 0 0 1
20 Pumping system cycles 0 0 0 52
21 Time to stop 0 0 0 75
31
*
Gas module control
32 Final stage purge nitrogen flow 0 0 0 462
35 Total nitrogen purge flows 0 0 0 190
39 Exhaust pressure 0 0 0 59
40 Shaft-seals purge pressure 0 0 0 397
45 Nitrogen supply status 0 0 0 4
46 Interstage purge status 0 0 0 3
47Inlet purge status 0001
48 Time for gas sensors to zero 0 0 0 68
51
*
Sensor module control
52 Analogue water flow 0 0 0 265
53 Active gauge pressure 0 0 0 2.1 x 10
-5
54 Mechanical booster pump motor temperature 0 0 0 3210
55 Dry pump motor temperature 1 13 2 1319
56 Exhaust temperature 0 0 0 4180
57 Dry pump body temperature 0 0 0 3536
58Dry pump oil status 0001
59 Mechanical booster pump oil status 0 0 0 1
60Water flow status 0001
111
*
NIM (Network Interface Module)
121
*
Parallel (tool) interface module
131 Parallel (tool) interface input status 0 15 0 0
140 Parallel (tool) interface output status 0 15 0 0
151
*
Auxiliary interface
160 Auxiliary interface input status 0 0 0 78
169 Auxiliary interface output status 0 0 0 24
172Inverter current 0007
173 Inverter power 0 0 0 6
174 Inverter speed 0 0 0 1000
175Inverter torque 0005
176 Inverter status 0 0 0 000F000F
245 GRC status 1 1 0 000F000F
*
These parameters can only be specified in ?I query messages.
Table 15 - Simulated Pumping System Data
{parameter} Description
{priority
level}
{alarm
type}
{bitfield
status}
{value}
