© Edwards Limited 2013. All rights reserved. Page 81
Edwards and the Edwards logo are trademarks of Edwards Limited.
Service, spares and accessories
B800-00-880 Issue D
7.3.4 NW16 and NW25 Ports
nEXT pumps are supplied with NW25 exhaust and booster ports. The item numbers of replacement ports are given
below.
7.4 Accessories
7.4.1 Installation
The accessories available for use with the nEXT pumps are described in the following section. Figure 20 and 21 shows
how the accessories are fitted to the pump.
7.4.2 ACX air cooler
An ACX air cooler can be fitted to the nEXT pump, refer to Section 3.10 to check the suitability of air cooling in a
particular application.
7.4.3 WCX water cooler
A water cooler can be fitted to the nEXT pump refer to Section 2.5 to check the suitability of the cooling water
supply.
Table 37 - NW16 and NW25 ports
Port Item Number
NW25 B800-00-809
NW16 B800-00-806
Table 38 - ACX air cooler
Air Cooler Current draw Item number
ACX nEXT radial fan 135 mA B580-53-175
ACX nEXT axial fan 135 mA B580-53-185
ACX nEXT radial fan (with Phoenix connector) 135 mA B580-53-170
ACX nEXT axial fan (with Phoenix connector) 135 mA B580-53-180
Table 39 - WCX water cooler
Water Cooler Item Number
WCX nEXT water cooling kit B800-00-815
