© Edwards Limited 2013. All rights reserved. Page 83
Edwards and the Edwards logo are trademarks of Edwards Limited.
Service, spares and accessories
B800-00-880 Issue D
7.4.7 Vent port adaptor
The vent port adaptor has a 1/8 inch BSP male thread that can be screwed into both the vent port and purge port,
making them suitable for NW10 fittings.
7.4.8 PRX purge restrictor
The PRX10 is a modified DN10NW centring ring that filters the purge gas and restricts its flow rate to the
recommended flow of 25 sccm. A vent port adaptor must be fitted to the purge port in order to connect a purge
restrictor to the pump.
7.4.9 C-Clamp Adaptor Kit
The NW25 exhaust and booster port of the nEXT pump can be removed and replaced with a C-clamp connection.
The following tool kit and parts are available
7.4.10 Interface Cable
An interface cable connects the nEXT pump to a PC. Serial commands are then used to control and monitor the nEXT
pump.
7.4.11 TIC PC Program
The TIC PC program is a piece of PC-based software that can be used fore retrieving and setting the user configurable
parameters in the pump. It also enables monitoring and data logging of the pumping system.
Table 43 - Vent port adaptor
Vent port adaptor Item Number
Vent port adaptor NW10 -1/8 inch BSP male B580-66-011
Table 44 - PRX purge restrictor
Item Item Number
PRX10 purge restrictor B580-65-001
Table 45 - C-clamp adaptor tool kit
Tool kit Item Number
Port removal and insertion tool B800-00-807
Table 46 - C-clamp adaptor port kit
Port kit Item Number
C-Clamp and NW25 flange adaptor B800-00-813
Table 47 - Interface cable
Item Item Number
nEXT Interface Cable B800-00-808
