If the one-bit telegram is selected, this parameter defines
the value of the telegram to be sent when sound is
detected (start event).
Send only detection
event
no/yes
Choose no to send the telegram of opposite value to that
of detection (end of event), at the end of the follow-up
time
Detection retention time
1 s. .. 2 ore
If no sound is detected the telegram related to the end of
the event is sent at the end of this time.
Correction offset
[if output type = decibel]
-7 .. +7
Correction offset of the value in dB
Sending interval
never, 1 minute hours
Periodical sending time
Send on variation
[if output type = decibel]
never
Value of deviation from the previous value that generates
the sending of the data.
Send on variation
[if output type = Intensity]
never, 2*10
-9
.. 8.19 * 10
-6
Value of deviation from the previous value that generates
the sending of the data.
13. Channels configuration
The device has 5 independently configurable
channels, below we see the possible settings and
functions, they are the same for each channel.
The possible types of functions are as follows; not all
functions are possible for all models, the BASIC
model does not provide any function related to
brightness:
 No action
 Simple presence
 Automatic presence, illuminance depending
 semi-automatic presence
 semi-automatic presence, illuminance
depending
 Constant illuminance
 Constant illuminance, presence depending
 Constant illuminance, presence depending,
semi-automatic
Some settings are recurring and may appear on
more than one function, these settings will be
described below.
Follow-up time
The follow-up time defines how long the device,
after the detection of a presence, must consider the
PRESENCE status valid even if it has not detected
other movements. If a new movement is detected
during the follow-up time, it is restarted. At the end
of this time, the device goes into the ABSENCE
state.
KNX PARAMETER
SETTINGS
Follow-up time
Hours
0 .. 24
Minutes
0 .. 59
Seconds
0 .. 59
It is possible to use the information of the sound
sensor to extend the follow-up time (in this case the
sound is considered as a new presence detection). It
is also possible to define a time at the end of the
follow-up within which the detection of a sound
reactivates the follow-up time even if this has
expired..
KNX PARAMETER
SETTINGS
Use sound sensor event
during follow-up time
no/yes
If you select yes the sound sensor will be considered for
the whole follow-up time.
Sound sensor reaction
time on absence
0 .. 255 s. [0=no reaction]
At the end of the follow-up time the sensor goes into the
ABSENCE state, within the time defined by this parameter
it can return to PRESENCE and reactivate the follow-up
time upon detection of a sound whose intensity differs
from the average value of the environment in where it is.
