Commands sequences
This function allows you to associate to short and
long press, sequences of different commands on the
bus.
For each button this function is available for short
and long press or as toggle function.
The sequence consists of 2 or 3 commands which
can each be sized as 1 bit or 1 byte.
Once defined the number of elements in the
sequence (2 or 3) and their size (1-bit / 1 byte), you
can associate different commands to each element
of the sequence or decide to send commands only
on one of the two events.
The waiting time between a command and the next
is configurable
Each object communication can be connected to a
different group address.
For example it is possible to define a sequence:
short press
(operation 1)
COMFORT
(to a thermostat)
ECONOMY
(to a thermostat)
Commands sequences (1 bit)
This function allows you to send sequences of 1-bit
commands to multiple objects. The sequence can
be defined on 2 or 3 objects. Each time the button
connected to the input is pressed, the next step of
the defined sequence is sent.
This set parameter defines the number of 1-bit objects
that will be visible and that will send the values 0 or 1
on the bus
Number of steps in the
sequence
Indicates the number of steps in the sequence.
Long press to restart
sequence
Allows to associate the long action of the button
connected to the input with the restart action of the
sequence at step zero
Restart and send first
Send long step and
restart
Restart and send first
Long press determines the sending of the step 1
Send long step and restart
Long press determines the sending of the next step
and brings the sequence to the initial step.
<Different combinations
of values of a,b,c objects>
Defines what happens when long press is performed
(depends on Restart function parameter)
This parameter defines whether, in the passage from
one step to the next, all the values associated with the
one-bit objects must always be sent, or only those that
change.
Combinations of on and
off on 2 or 3 1-bit objects
Determines the combination associated with a
sequence step using 2 or 3 1-bit objects.
Set RGB color
This function allows you to associate a short press of
the button to a command on the bus in order to set
a RGB color. The "RGB object type" parameter
defines whether the command is sent with a single
3-byte object or 3x1-byte objects. It is also possible
to enable a feature associated with a long press that
allows to change the color which is sent with a
short press. During long press the color transition is
performed and at the time of release the selected
color is stored; this means that from now every time
