HVAC MODE obj. (automatic heat / cool)
Thermostat
control mode
the switching from heating to cooling mode and
vice versa is automatic. With this setting it is
necessary to set an insensitive zone as in parameter
Dead zone
Whenever temperature becomes greater than :
Setpoint comfort heating + (Dead Band / 2)
active
control is cooling; when temperature becomes less
than:
Setpoint comfort cooling - (Dead Band / 2)
active control is heating
It is possible to set the comfort setpoint as the
center of the dead band using the relative
parameter; the comfort value is common to the
heating and cooling mode.
Setpoint H/C
Dead band center
SETPOINT COMFORT, STANDBY, ECONOMY
These 2 byte objects are used to set the setpoint
values for COMFORT, STAND-BY, ECONOMY mode.
Whenever change, the setpoint are in saved in
memory.
After download these setpoint are reset to values
according to ETS parameter; on power up these
object are set according to last values before power
down.
Use these communication objects to
change current setpoint for every HVAC
Mode according to the current active control
(heating or cooling)
Action to execute for
setpoint
modify relative
modify absolute
If you set this parameter to " modify relative ", the
thermostat will take into account the new value set but
will still consider the setpoint set in ETS as a reference to
determine the allowed variation range (± 1, ± 2, ± 3, .. );
choosing instead the value "absolute change" also this
range will be recalculated.
