1. Introduction
This manual is intended for use by KNX® installers
and describes the functions and parameters of the
KNX presence sensors "E" series and how it is
possible to change the settings and configurations
using the ETS software tool.
The range of Eelectron presence sensors is suitable
for ceiling mounting and consists of 5 versions: 4
suitable for mounting up to 4 m in height and a
HIGH BAY stallation up to 16 m
height.
All versions have a rear connector with 3 digital
inputs that can be connected to potential-free
buttons or switches and used for on / off, dimming,
roller shutters or blinds / scenarios, sequences, step-
by-step commands, etc.
On STANDARD, MULTI, SPACE and HIGH BAY
models one of the 3 inputs can be configured as
analogical input for the connection of NTC
temperature probes (see eelectron probes code
TS00A01ACC / TS00B01ACC) with which is possible
to send the temperature measurement on the bus
or manage a complete thermostat module. The
thermostat manages 2 stages with integrated PI
controller for the control of heating and cooling
equipment, valves, 2- and 4-pipe fan coils, etc.
PRESENCE DETECTION
3 DIGITAL INPUTS
PRESENCE DETECTION
LIGHTING CONTROL
2 DIGITAL INPUTS
1 ANALOG / DIGITAL INPUT
PRESENCE DETECTION
LIGHTING CONTROL
TEMPERATURE CONTROL [1]
HUMIDITY SENSOR
SOUND SENSOR
2 DIGITAL INPUTS
1 ANALOG / DIGITAL INPUT / SMART
SENSOR
PRESENCE DETECTION
LIGHTING CONTROL
2 DIGITAL INPUTS
1 ANALOG / DIGITAL INPUT
[1]: WITH EMBEDDED TEMPERATURE SENSOR.
The STANDARD, MULTI, SPACE and HIGH BAY
versions include a brightness sensor for controlling
ambient lighting, the MULTI and SPACE versions
also include humidity and temperature sensors with
relative control algorithms and a sound sensor that
can be used in environments with parts not totally
visible to the infrared sensor.
The humidity sensor (MULTI and SPACE models) can
measure the relative humidity in the room and
provide control with hysteresis of humidification
and dehumidification devices; for this model of
sensors it is possible to connect an accessory cod.
SM03E01ACC which allows to measure temperature
and CO
2
. The CO
2
measurement is available on the
bus and from ETS it is possible to manage a
threshold control with hysteresis for both on / off
and proportional algorithm .
Presence detection, based on a passive infrared
sensor, has 5 independent configurable channels
with different functions that can be activated:
presence with or without brightness control and
with automatic or semi-automatic detection;
constant brightness independent or dependent on
presence and with automatic or semi-automatic
activation.
The BASIC sensor manages presence detection only.
There are 12 logic blocks with which is possible to
create simple expressions with a logical or threshold
operator or complex expressions with algebraic and
conditional operators and also is possible to use
predefined algorithms such as proportional controls
of temperature and humidity or dew point
calculation.
The device also integrates the "Virtual ;
the field of application is the hotel room: through a
magnetic sensor installed on the door and
connected to a digital input (also one of the sensor
itself), accurate presence information is managed.
The presence detection solution can recognise the
presence of people in the room using one or more
dedicated sensors. It also detects an unexpected
presence and is able to differentiate multiple
behaviours.
