This possibility must be considered during
installation, so communication objects must be
connected as described below if you want to switch
runtime from one configuration (2 single rooms) to
another (one double room) and vice versa.
To handle this situation both "Virtual Holder"
modules of the 2 single rooms must be activated
and configured.
The principle is to connect the sensors (door,
presence and sniffer) of room 1 to room 2 and vice
versa; however, the "Subordinate to Remote Inputs
Enable" parameter for each single Remote Input
should be properly configured.
For sensors located in Room 1, this parameter must
be set to "not subordinate" on room 1 "Virtual
Virtual Holder
.
The same principle must be applied to room 2
sensors that are "subordinate" only for the
connections to room 1.
Setting the value "1" on the "Remote Inputs Enable"
object for the "Virtual Holder" of each room each
module will consider all sensors connected to it; by
setting this CO to "0" each "Virtual Holder" only
considers the sensors connected to its
set as "not subordinate"
For a connection diagram of this function see Fig. 2.
