4.8.8. MODBUS Registers
To aid PLC programming the following table shows the main MODBUS registers.
Address
Registers
Group
Name
Description
Note
Input Registers
- (Read Only) function 0x04
30007
0
Concentration
Concentration [100*%]
e.g. 67.89% = 6789
30008
AD average
Last 8 AD Conversions Averaged Value
30009
Oil temp / Medium temp
Temperature [100*°C]
Oil/Medium temperature calculation
result [100*°C] e.g. 24.73°C = 2473
30014
Temperature compensated
ADC Value for Low Limit
Difference between current AD converter
value and calibrated low limit value,
temperature compensated
30050
3
Firmware Version
Day of compilation
Firmware day, month and year of
compilation. FW Version/Revision
30051
Month of compilation
30052
Year of compilation
30053
FW Version
30054
FW Revision
30055
Sensor Board Type
1 …Low Range; 2 … Full Range
Input Registers
- (Read/Write) functions 0x03; 0x10
40010
1
CalLowLimit ADC
Calibrated Low Limit ADC value
40011
CalHiLimit ADC
Calibrated Hi Limit ADC value
40012
Low Limit
Calibrated Low Limit [100*%]
40013
Hi Limit
Calibrated Hi Limit [100*%]
40014
CalLoLimit Temp
Calibrated Low Limit Temperature [100*°C]
40015
CalHiLimit Temp
Calibrated Hi Limit Temperature [100*°C]
40016
LoopLimit
Current loop limit [10*%]
40034
3
Setting Register
xxxx_x1xxb=backlight ON
xxxx_x0xxb=backlight OFF
xxx0_0xxxb=Laboratory Calibration
xxx0_1xxxb=Two-point Calibration
xxx1_1xxxb=High-point Calibration
xx1x_xxxxb=Open Collector Output Enabled
xx0x_xxxxb=Open Collector Output Disabled
x0xx_xxxxb=Modbus Absolute Addressing
x1xx_xxxxb=Modbus Relative Addressing
40035
k - constant
100*k
Default value 4860
40036
q - constant
Default value 28109
