EET PMC-33M-A User Manual

CET Electric Technology
23
Display 7
PF1
1
PF2
1,4,5
PF3
1,3,4,5
Display 8
U1 Angle
2
U2 Angle
2,4,5
U3 Angle
2,3,4,5
Display 9
I1 Angle
I2 Angle
4,5
I3 Angle
3,4,5
Display 10
U1 Fund.
2
U2 Fund.
2,4,5
U3 Fund.
2,3,4,5
Display 11
I1 Fund.
I2 Fund.
4,5
I3 Fund.
3,4,5
Display 12
P1 Fund.
1
P2 Fund.
1,4,5
P3 Fund.
1,3,4,5
Display 13
PF1 Fund.
1
PF2 Fund.
1,4,5
PF3 Fund.
1,3,4,5
Display 14
I1 Present Dmd
I2 Present Dmd
5
I3 Present Dmd
3,5
Display 15
I1 Maximum Demand of This Month (Since Last Reset)
Display 16
I2 Maximum Demand of This Month (Since Last Reset)
4,5
Display 17
I3 Maximum Demand of This Month (Since Last Reset)
3,4,5
Display 18
I1 Maximum Demand of Last Month (Before Last Reset)
Display 19
I2 Maximum Demand of Last Month (Before Last Reset)
4,5
Display 20
I3 Maximum Demand of Last Month (Before Last Reset)
3,4,5
Display 21
U1 Max. of This Month (Since Last Reset)
1,5
Display 22
U2 Max. of This Month (Since Last Reset)
1,4,5
Display 23
U3 Max. of This Month (Since Last Reset)
1,3,4,5
Display 24
U12 Max. of This Month (Since Last Reset)
4
Display 25
U23 Max. of This Month (Since Last Reset)
3,4,5
Display 26
U31 Max. of This Month (Since Last Reset)
3,4,5
Display 27
I1 Max. of This Month (Since Last Reset)
Display 28
I2 Max. of This Month (Since Last Reset)
4,5
Display 29
I3 Max. of This Month (Since Last Reset)
3,4,5
Display 30
P1 Max. of This Month (Since Last Reset)
1
Display 31
P2 Max. of This Month (Since Last Reset)
1,4,5
Display 32
P3 Max. of This Month (Since Last Reset)
1,3,4,5
Display 33
Q1 Max. of This Month (Since Last Reset)
1
Display 34
Q2 Max. of This Month (Since Last Reset)
1,4,5
Display 35
Q3 Max. of This Month (Since Last Reset)
1,3,4,5
Display 36
S1 Max. of This Month (Since Last Reset)
1
Display 37
S2 Max. of This Month (Since Last Reset)
1,4,5
Display 38
S3 Max. of This Month (Since Last Reset)
1,3,4,5
Display 39
PF1 Max. of This Month (Since Last Reset)
1
Display 40
PF2 Max. of This Month (Since Last Reset)
1,4,5
Display 41
PF3 Max. of This Month (Since Last Reset)
1,3,4,5
Display 42
U1 Max. of Last Month (Before Last Reset)
1,5
Display 43
U2 Max. of Last Month (Before Last Reset)
1,4,5
Display 44
U3 Max. of Last Month (Before Last Reset)
1,3,4,5
Display 45
U12 Max. of Last Month (Before Last Reset)
4
Display 46
U23 Max. of Last Month (Before Last Reset)
3,4,5
Display 47
U31 Max. of Last Month (Before Last Reset)
3,4,5
Display 48
I1 Max. of Last Month (Before Last Reset)
Display 49
I2 Max. of Last Month (Before Last Reset)
4,5
Display 50
I3 Max. of Last Month (Before Last Reset)
3,4,5
Display 51
P1 Max. of Last Month (Before Last Reset)
1
Display 52
P2 Max. of Last Month (Before Last Reset)
1,4,5
Display 53
P3 Max. of Last Month (Before Last Reset)
1,3,4,5
Display 54
Q1 Max. of Last Month (Before Last Reset)
1
Display 55
Q2 Max. of Last Month (Before Last Reset)
1,4,5
Display 56
Q3 Max. of Last Month (Before Last Reset)
1,3,4,5
Display 57
S1 Max. of Last Month (Before Last Reset)
1
Display 58
S2 Max. of Last Month (Before Last Reset)
1,4,5
Display 59
S3 Max. of Last Month (Before Last Reset)
1,3,4,5
Display 60
PF1 Max. of Last Month (Before Last Reset)
1
Display 61
PF2 Max. of Last Month (Before Last Reset)
1,4,5
Display 62
PF3 Max. of Last Month (Before Last Reset)
1,3,4,5
Table 3-4 Phase Display
Notes:
1) This screen is not shown if the Wiring Mode is set to 3P3W.
2) For U/I Angle/Fund.:
 U1 = Uan, U2 = Ubn, U3 = Ucn in 3P4W mode
 U1 = Uab, U2 = Ubc, U3 = Uca in 3P3W and 1P2W L-L modes
3) This screen is not shown if the Wiring Mode is set to 1P3W.
4) This screen is not shown if the Wiring Mode is set to 1P2W L-N.
5) This screen is not shown if the Wiring Mode is set to 1P2W L-L.
