Table 5-24 SOE Event Classification
3) Clear All Data via Front Panel or Communication means to clear 3-Phase Total Energy registers,
Phase A/B/C Energy registers, All Maximum Demands, All Max./Min. Logs, Device Operating Time,
SOE Log and All DI Pulse Counters.
5.8 Device Setup
5.8.1 Basic Setup Parameters
Register
Property
Description
Format
Range, Default*
6000
RW
PT Primary
1
UINT32
1 to 1,000,000 V, 100*
6002
RW
PT Secondary
UINT32
1 to 690V, 100*
6004
RW
CT Primary
UINT32
1 to 30,000A, 5*
6006
RW
CT Secondary
UINT32
1 to 5A, 5*
6008~6018
RW
Reserved
UINT32
6020
RW
Wiring Mode
UINT16
0=DEMO, 1=1P2W L-N,
2=1P2W L-L, 3=1P3W L-L-N
4=3P3W, 5=3P4W*
6021
RW
PF Convention
UINT16
0=IEC*, 1=IEEE, 2=-IEEE
6022
RW
kVA Calculation
UINT16
0=Vector*, 1=Scalar
6023
RW
Ia Polarity
UINT16
0=Normal*, 1=Reverse
6024
RW
Ib Polarity
UINT16
6025
RW
Ic Polarity
UINT16
6026~6027
RW
Reserved
UINT16
6028
RW
THD Calculation
2
UINT16
0= THDf*, 1= THDr
6029
RW
Demand Period
UINT16
1 to 60 (minutes), 15*
6030
RW
Number of Sliding Windows
UINT16
1* to 15
6031
RW
Predicted Response
UINT16
70* to 99
6032
RW
Arm before Execute
UINT16
0=Disabled*, 1=Enabled
6033
RW
Self-Read Time
3
UINT16
Default=0xFFFF
(Manual Reset)
6034
RW
Reserved
UINT16
6035
RW
Energy Pulse Constant
UINT16
0=1000 imp/kxh*
1=3200 imp/kxh
6036
RW
LED Energy Pulse
UINT16
0=Disabled
1=kWh Total Energy Pulse*
2=kvarh Total Energy Pulse
6037
RW
Backlight Timeout
UINT16
0 to 60 mins, 5*
Table 5-25 Basic Setup Parameters
Notes:
1) The value of [PT Primary/PT Secondary] cannot exceed 10000.
15
0
Setup Changed via Front Panel
16~29
0
Reserved
30
0
Clear 3-Ø Total and Per-Phase Energy
Registers via Communication
31
Reserved
32
0
Reserved
33
0
Clear Maximum Demand of This Month
(Since Last Reset) via Communication
34
0
Clear All Demand Registers via
Communication
35
0
Clear Max./Min. Logs of This Month
(Since Last Reset) via Communication
36
0
Clear All Max./Min. Logs via Communication
37
0
Clear All Data via Communication
2
38
0
Clear SOE Log via Communication
39
0
Clear DIx Pulse Counter via Communication
(x=1 to 4)
40
0
Clear All DI Pulse Counters via
Communication
41
0
Clear Device Operating Time via
Communication
42
0
Reserved
43
0
Setup Changes via Communication
44
0
Preset Energy Value via Communication
