Table 5-20 Min. Log of Last Month (Before Last Reset)
Notes:
1) When the Wiring Mode is 1P2W L-N or 1P2W L-L, the Phase B and Phase C Min. measurements of
Last Month (Before Last Reset) have no meaning, and their registers are reserved.
2) When the Wiring Mode is 1P3W, the Phase C Min. measurements of Last Month (Before Last Reset)
have no meaning, and their registers are reserved.
5.6.5 Max./Min. Log Structure
Table 5-21 Max./Min. Data Structure
5.7 SOE Log
The SOE Log Pointer points to the register address within the SOE Log where the next event will be
stored. The following formula is used to determine the register address of the most recent SOE event
referenced by the SOE Log Pointer value:
Register Address = 10000 + Modulo(SOE Log Pointer-1/100)*8
