EET PMC-33M-A User Manual

CET Electric Technology
47
10048~10055
RO
Event 7
10056~10063
RO
Event 8
10064~10071
RO
Event 9
10072~10079
RO
Event 10
10080~10087
RO
Event 11
10088~10095
RO
Event 12
…
…
10792~10799
RO
Event 100
Table 5-22 SOE Log
Notes:
1) SOE Log Data Structure
Offset
Property
Description
Unit
+0
RO
High-order Byte: Event Classification
See Table 5-24
SOE Classification
RO
Low-order Byte: Sub-Classification
+1
RO
Record Time: Year
0-99 (Year-2000)
RO
Record Time: Month
1 to 12
+2
RO
Record Time: Day
1 to 31
RO
Record Time: Hour
0 to 23
+3
RO
Record Time: Minute
0 to 59
RO
Record Time: Second
0 to 59
+4
RO
Record Time: Millisecond
0 to 999
+5
RO
High-order Byte: Reserved
-
RO
Low-order Byte: Status
2
-
+6 to +7
RO
Event Value
2
-
Table 5-23 SOE Log Data Structure
2) SOE Classification
Event
Classification
Sub-
Classification
Status
Event
Value
Description
1=DI Changes
1
1 / 0
DI1 Inactive / DI1 Active
2
1 / 0
DI2 Inactive / DI2 Active
3
1 / 0
DI3 Inactive / DI3 Active
4
1 / 0
DI4 Inactive / DI4 Active
2=DO Changes
1
1 / 0
DO1 Operated/Released by Remote Control
2
1 / 0
DO2 Operated/Released by Remote Control
3~10
Reserved
11
1 / 0
DO1 Operated/Released by Setpoint
12
1 / 0
DO2 Operated/Released by Setpoint
13~20
Reserved
21
1 / 0
DO1 Operated/Released by Front Panel
22
1 / 0
DO2 Operated/Released by Front Panel
23~30
1 / 0
Reserved
31
0
DO1 Released When Pulse Time Out
32
0
DO2 Released When Pulse Time Out
3=Setpoint
1
1 / 0
Trigger
Value /
Return
Value
Over Uln Setpoint Active/Return
2
1 / 0
Over Ull Setpoint Active/Return
3
1 / 0
Over Current Setpoint Active/Return
4
1 / 0
Over In (calculated) Setpoint Active/Return
5
1 / 0
Over Frequency Setpoint Active/Return
6
1 / 0
Over kW Total Setpoint Active/Return
7
1 / 0
Over kvar Total Setpoint Active/Return
8
1 / 0
Over kVA Total Setpoint Active/Return
9
1 / 0
Over PF Total Setpoint Active/Return
10
1 / 0
Over kW Total Present Demand Setpoint
Active/Return
11
1 / 0
Over kvar Total Present Demand Setpoint
Active/Return
12
1 / 0
Over kVA Total Present Demand Setpoint
Active/Return
13
1 / 0
Over kW Total Predicted Demand Setpoint
Active/Return
14
1 / 0
Over kvar Total Predicted Demand Setpoint
Active/Return
15
1 / 0
Over kVA Total Predicted Demand Setpoint
