3.3 Data Display
Throughout this document, the phase-to-neutral notations of A/B/C and L1/L2/L3 as well as the phase-
to-phase notations of AB/BC/CA and L12/L23/L31 may be used interchangeably for specifying a certain
parameter to be a phase-to-neutral or phase-to-phase value, respectively.
The following sections illustrate the available measurements for each display option. Depending on the
Wiring Mode selected, certain measurements may not be available. For example, the per-phase Uln,
Uln Average, per-phase kW, kvar, kVA and PF measurements are not available when the Wiring Mode
is set to 3P3W or 1P2W L-L.
3.3.1 System
Display Screens
1
st
Row
2
nd
Row
3
rd
Row
Display 1 (Default)
kW Total
I avg
PF Total
Display 2
Frequency
Uln avg
1
Ull avg
3,4
Display 3
kW Total
kvar Total
kVA Total
Display 4 (Pres Demand)
kW Total
kvar Total
kVA Total
Display 5
Fundamental kW Total
Fund. PF Total
Display 6
Inc (In Calculated)
1,2,4
Display 7
U Unbalance
2,4
I Unbalance
2,4
Display 8
Device Operating Time (Run Hours)
Display 9
kW Total Maximum Demand of This Month (Since Last Reset)
Display 10
kvar Total Maximum Demand of This Month (Since Last Reset)
Display 11
kVA Total Maximum Demand of This Month (Since Last Reset)
Display 12
kW Total Maximum Demand of Last Month (Before Last Reset)
Display 13
kvar Total Maximum Demand of Last Month (Before Last Reset)
Display 14
kVA Total Maximum Demand of Last Month (Before Last Reset)
Display 15
Uln avg Max. of This Month (Since Last Reset)
1,4
Display 16
Ull avg Max. of This Month (Since Last Reset)
4
Display 17
I avg Max. of This Month (Since Last Reset)
4
Display 18
Frequency Max. of This Month (Since Last Reset)
Display 19
kW Total Max. of This Month (Since Last Reset)
4
Display 20
kvar Max. of This Month (Since Last Reset)
4
Display 21
kVA Max. of This Month (Since Last Reset)
4
Display 22
PF Total Max. of This Month (Since Last Reset)
4
Display 23
U Unbalance Max. of This Month (Since Last Reset)
2,4
Display 24
I Unbalance Max. of This Month (Since Last Reset)
2,4
Display 25
Uln avg Max. of Last Month (Before Last Reset)
1,4
Display 26
Ull avg Max. of Last Month (Before Last Reset)
4
Display 27
I avg Max. of Last Month (Before Last Reset)
4
Display 28
Frequency Max. of Last Month (Before Last Reset)
Display 29
kW Total Max. of Last Month (Before Last Reset)
4
Display 30
kvar Max. of Last Month (Before Last Reset)
4
Display 31
kVA Max. of Last Month (Before Last Reset)
4
Display 32
PF Total Max. of Last Month (Before Last Reset)
4
Display 33
U Unbalance Max. of Last Month (Before Last Reset)
2,4
Display 34
I Unbalance Max. of Last Month (Before Last Reset)
2,4
Table 3-3 System Display
Notes:
1) This screen is not shown if the Wiring Mode is set to 3P3W.
2) This screen is not shown if the Wiring Mode is set to 1P3W.
3) Ull avg=U12 when the Wiring Mode is set to 1P3W.
4) This screen is not shown if the Wiring Mode is set to 1P2W L-N or 1P2W L-L.
3.3.2 Phase
Display Screens
1
st
Row
2
nd
Row
3
rd
Row
Display 1
U1
1,5
U2
1,4,5
U3
1,3,4,5
Display 2
U12
4
U23
3,4,5
U31
3,4,5
Display 3
I1
I2
4,5
I3
3, 4,5
Display 4
P1
1
P2
1,4,5
P3
1,3,4,5
Display 5
Q1
1
Q2
1,4,5
Q3
1,3,4,5
Display 6
S1
1
S2
1,4,5
S3
1,3,4,5
