E F A P O W E R EV- H C - I N S T A L L A T I O N A N D U S E R M A N U A L
10 | 28
5.2.2 SURFACE PREPARATION
Each Charging Station must be fixed to a pole or a wall by a fixing plate.
5.2.3 RESOURCES FOR INSTALLATION
For the installation of EFAPOWER EV-HC Station the following resources are going to be needed:
Fasteners:
 3x Screws M4 + 3x matching Anchors
 If EV-HC with cable, for cable holder: 2x Screw M4 + 2x matching Anchor
End terminals for input wiring by Unit:
EV-HC 3 / 7
 3 (three) end terminals for cable according to Table 5 or according to local codes (1 phase + neutral +
protective ground)
EV-HC 11 / 22
 5 (five) end terminals for cable according to Table 5 or according to local codes (3 phases + neutral +
protective ground)
16A
32A
16A
32A
Table 5 - Input lines –cross-section range
* These cross-sections are applied to copper cable length up
to 50m or according to local codes. For higher distances
contact the manufacturer.
max A
Min cross-section*
Terminal block section
16 A
2,5mm
2
4mm
2
32 A
4mm
2
4mm
2
Tools:
 Screwdriver - for wall mount
 Crimping tool - for power and earth cables
 Torque screwdriver with flat blade - for input terminal blocks
5.2.4 SITE VERIFICATION AND INSPECTION
 Check if Home Charger has the appropriate upstream protection depending on the configuration of it
 Verify if the neutral is of type TT or TN. Only these two regimes guarantee a good and correct
functioning of the EFAPOWER EV-HC residual current device
 Verify the earth circuit resistance: it should be according to IEC 60364/GB 16895.3, and other applicable
standards. In either case it must be under 150 Ω
 Verify if the main distribution board has conditions to support one more circuit with the characteristics
required depending on the model
 Execute and test the installation according to IEC 60364 standard or local regulations for CE marked
units and according to GB 16895.3, GB/T 16895.10, GB16895.5 standards or local regulations for GB
marked units
 A test document will be issued by the installer responsible as a guarantee to the user that the
Homecharger was properly installed and ready to supply energy to charge the EV battery
Table 4 – Max current by phase
