E F A P O W E R EV- H C - I N S T A L L A T I O N A N D U S E R M A N U A L
20 | 28
Switch on residual current device and the circuit breaker (if applicable) in the Charging Station:
Residual current devices: Q0
Circuit breakers: Q1 (if socket output in 32A models)
The RCD can be armed by removing the left window and moving up the lever. There is a test button for
operation and differential protection test.
After connecting the charging station for the first time, wait a few seconds and the EV-HC Station should be
ready to use.
AT THIS POINT THE COMMISSIONING CHECK LIST REPORT, PROVIDED WITH THIS MANUAL, SHALL BE FILLED IN
AND SENT TO EFACEC VIA E-MAIL: serviceEEM@efacec.com.
